Defibrillator

Operations
Semi-automatic and fully automatic versions

Waveform
Biphasic Truncated exponential (BTe), with automated voltage and duration compensation for patient impedance

Range of selected energy
100 to 360 J (adult)
10 to 100 J (child)

Energy default
200-300-360J (adult)
50-70-100J (child)
Default configuration meets AHA/ERC Guidelines 2015.

Energy accuracy
±2 J or ±10% of setting, whichever is greater

Power on time
< 2 seconds

ECG analysis time
< 5 seconds

Charge time
9 seconds (as device is pre-charged during ECG analysis)

Time from power on to shock ready
< 8 seconds (200J, new battery, 20 ±5°C)

Mindray shockable rhythm analysis algorithm
Acquires and analyzes the patient’s ECG signals to determine whether or not to give a defibrillation shock

Sensitivity and specificity
Meets AAMI DF80 specifications and IEC 60601-2-4 specifications

Patient impedance range
25 to 300 Ω

User Prompts

User prompts
Voice prompts

CPR coaching
Voice guide
CPR metronome
CPR real-time feedback*
Meets AHA/ERC Guidelines 2015 and/or can be configured locally

Controls

Lid release/ON-OFF
Controls device power on/off

Shock button
Delivers energy when button presses by the user (semi-automatic only)

Adult/child mode switch
Switch to child mode for reduced energy and appropriate CPR guidance

Language button
Optional feature allows the user to switch between max. 3 languages

Physical Characteristics

Dimension
210 mm (w) × 286 mm (d) × 78 mm (h)

Weight
2.0 kg (including one battery)

Environmental

Dust/water resistance
IP55

Temperature
Operating: -5 to 50°C
Short-term storage: -30 to 70°C for a maximum of 7 days
Long-term storage: 15 to 35°C

Humidity
Operating/storage: 5 to 95 % (non-condensing)

Altitude
Operating/storage: -381 m to +4575 m

Shock
RTCA-DO-160G-2010, Section 7

Vibration
IEC60601-1-12, 10.1.3, 10.1.4
MIL-STD-810G-2008, method 514.6
Category 13, Category 14, Category 20, Category 24
EN13718-1, 4.7.2

Bump
EN1789, 6.3.4.2

Drop
1.5 m

EMC
IEC60601-1-2: 2014
EN13718-1, 4.5.7
IEC 60601-1-12, 1

Battery

Type
Lithium manganese dioxide (Li/MnO2), disposable, 4200 mAh

Standby life
6 years (at 20±5°C, performing auto test every week, not in use, not sending self-test report)

5 years (at 20±5°C, performing auto test every day, not in use, not sending self-test report)

Capacity
With new battery at 20±5°C:
≥ 15 hours of operating time; provides max. 400 shocks @ 200J (±3 shocks < 1 minute)

Replace battery
Min. 10 shocks at 200 J and 30 minutes indication of operating time (at 20±5°C, typical)

Weight
300 g

Electrode Pads

Type
Pre-connected, disposable, for adult/child

Shelf life
5 years (from date of manufacture)

CPR Sensor*

Weight
Approximately 180 g (without battery)

Thickness
17.5 to 19 mm

Automatic Self-test

Auto-test
Daily, weekly, monthly, quarterly

Status indicator
Visual indicators indicating system readiness

Data Storage

Events
Up to 500 events

Voice recording
Up to 1 hour

CPR data
Up to 5 hours

Self-test reports
1000 records

Data export
Through USB flash memory

Communications

Wireless data transfer to AED-Alert™ 2.0 system
Through 5G/2.4G Wi-Fi or cellular (4G) network
